The Sound Barrier NX8M is a compact, passive two-way speaker system featuring an 8-inch low-frequency (LF) driver with a 2-inch voice coil and a 1-inch high-frequency (HF) driver mounted on a 90° x 50° horn that can be easily rotated for either horizontal or vertical orientation, depending on the venue’s requirements. Despite its small size, the Sound Barrier NX8M delivers impressive output capabilities.
As a standalone loudspeaker, the NX8M can be used in various professional settings, including distributed sound reinforcement, houses of worship (HoW), AV events, frontfill/infill, and even as a micro-stage monitor. When paired with an NX subwoofer, it becomes an ideal, user-friendly system for portable setups and installations that demand unobtrusive design while delivering pristine sound over short to medium distances. While the NX8M can function as a full-range passive two-way system without additional processing, using a controller/processor enhances its capabilities.
Constructed from 15mm birch plywood, the Sound Barrier NX8M features a screw-free steel grille, M8 inserts for wall brackets, eyebolt suspension, pole-mount socket and is finished in black textured paint.
Acoustic Specifications
FREQUENCY RESPONSE:
70Hz-20kHz (-3dB)
COVERAGE ANGLES:
100° (HORIZONTAL), 50° (VERTICAL) USER-ROTATABLE CONSTANT DIRECTIVITY HORN
SPL:
119dB CONTINUOUS, 125dB PEAK
SENSITIVITY:
95dB/1W/1M
IMPEDANCE:
8 OHM
Transducers
LOW FREQUENCY:
8-INCH, 2-INCH VOICE COIL
HIGH FREQUENCY:
1-INCH, 1.5-INCH VOICE COIL TITANIUM DRIVER WITH OVER-CURRENT & OVER VOTAGE PROTECTION
Power Section
TOTAL POWER HANDLING:
800 PEAK, 200W RMS
RECOMMENDED AMPLIFIER:
200W-600W into 8 Ohm
Input / Output Section
CONNECTORS:
2 x NL4 type (In / Out)
Construction
COLOR:
BLACK TEXTURED POLYURETHANE PAINT
HANDLES:
POCKET HANDLE
CABINET MATERIAL:
15MM BIRCH PLYWOOD
RIGGING:
8 x M8 FLYING POINTS, POLE-MOUNT SOCKET
GRILLE:
BLACK PERFORATED STEEL WITH CLOTH BACKING
Dimensions
WIDTH:Â 10.2 INCH / 260 mm
DEPTH:Â 9.5 INCH / 240 mm
HEIGHT:Â INCH / 420 mm
WEIGHT:Â 26.5 LB / 12 KG
