The Sound Barrier NX210S Subwoofer provides high-end performance and high power output (127dB Peak) in an extremely compact, lightweight package. The NX210’s speakon wiring ensures cost-effective and simple system implementation. This unit is ideal for installed sound reinforcement, A/V theater, and broadcast applications. Like other NEXONE series products, the Sound Barrier NX210 subwoofer is designed to work with advanced amplifiers, guaranteeing consistent performance and reliability of the highest standard.
Acoustic Specifications
FREQUENCY RESPONSE:
30Hz-180Hz (-10dB), 40Hz-200Hz (-3dB)
CONFIGURATION:
FRONT LOADED
MAX SPL:
127 DB
SENSITIVITY:
96dB/1W/1M
IMPEDANCE:
4 OHM
Transducers
LOW FREQUENCY:
2 x 10-INCH, 2-INCH VOICE COIL
Power Section
TOTAL POWER HANDLING:
1600W PEAK, 400W RMS
RECOMMENDED AMPLIFIER:
450W-600W into 8 Ohm
Input / Output Section
INPUT SIGNAL:
NEUTRIK® SPEAKON NL4
OUTPUT CONNECTORS:
NEUTRIK® SPEAKON NL4
Construction
COLOR:
BLACK HIGH RIGIDITY PAINT
HANDLES:
TWO WOOD HANDLE
CABINET MATERIAL:
18MM PLYWOOD
GRILLE:
STEEL WITH ACOUSTIC FOAM
Dimensions
WIDTH: 23.3 INCH / 600 mm
DEPTH: 18.9 INCH / 480 mm
HEIGHT: 11.4 INCH / 290 mm
WEIGHT: 46.3 LB / 21 KG
More details on Sound Barrier’s website
