The Sound Barrier LX210S serves as a powerful dual 10″ active subwoofer equipped with a healthy 1000W Class D amplifier. It is specifically designed to complement the LINE X2 system, providing additional low-frequency reinforcement where necessary. The modular nature of the LINE X2 system allows for seamless customization, enabling the addition or removal of subwoofers and columns to suit the specific requirements of different venues. Furthermore, the LX210S features a combination jack input and an NL4 output, allowing the connection of an extra LX210S.
The LX210S is a supplemental subwoofer. To connect the sub simply link the LX210S to the dedicated XLR output on the Sound Barrier LX210AS and your good to go. The gain can be adjusted via the rear panel of the LX210AS.
Product Specifications
Acoustic Specifications
FREQUENCY RESPONSE:
50Hz-200kHz
MAX SPL:
121 DB
Power Section
PEAK POWER HANDLING:
1500W (LF)
NOMINAL IMPEDANCE:
4 OHM
Transducers
LOW FREQUENCY:
2 x 10 INCH, 2.5-INCH VOICE COIL
Input / Output Section
INPUT SIGNAL:​​
COMBINATION JACK (1/4″ & XLR) ​
OUTPUT CONNECTORS:
XLR TO LX210S​
Processor Section
CROSSOVER FREQUENCIES:
200Hz, -24dB / OCT
PROTECTION:
PEAK / LIMITER LED INDICATOR
CONTROLS:
BASS GAIN, 3 DSP PRESETS
OPERATIONAL VOLTAGE:
100-240V, 50/60Hz SWITCHABLE
Construction
COLOR:
BLACK
HANDLES:
TWO SIDE WOOD RECESSED
MATERIAL:
MDF PLYWOOD
RIGGING:
N/A
FEET:
8 RUBBER FEET
GRILLE:
STEELÂ
Dimensions
WIDTH:Â 25.6 INCH / 650 mm
DEPTH:Â 19 INCH / 480 mm
HEIGHT:Â 14.2 INCH / 360 mm
WEIGHT:Â 61.7 LB / 28 KG
Additional specifications available at Sound Barrier’s website
