The Sound Barrier LX210AS packs a punch with its dual 10″ active subwoofers, and a robust 1500W Class D amplifier with a built-in DSP system. The modular design of the LINE X2 system allows for seamless customization, enabling the addition or removal of subwoofers and columns to suit various venue types. With preloaded DSP presets optimized for LINE X2 systems and LX12275 Column Arrays, the LX210AS ensures top-notch performance and efficiency across three recommended configurations. Additionally, it features a subwoofer gain control, an NL4 Speakon-type satellite output, and two XLR signal outs for connecting extra LX210AS units or Sound Barrier LX210S for added low-frequency support.
Built-in DSP
The 1500W LX210AS amplifier features a built-in DSP processor with 3 DSP presets to choose from depending on your setup.
It’s all about the low end
Do you need more bass? The LX210AS has two XLR signal outputs specifically labeled for an additional LX210AS or an LX210S active subwoofer.
Product Specifications
Acoustic Specifications
FREQUENCY RESPONSE:
50Hz-200kHz
MAX SPL:
121 DB
Power Section
POWER HANDLING:
2250W PEAK
(1500W LF + 750W FOR COLUMNS)
NOMINAL IMPEDANCE:
4 OHM
Transducers
LOW FREQUENCY:
2 x 10 INCH, 2.5-INCH VOICE COIL
Input / Output Section
INPUT SIGNAL:​​
COMBINATION JACK (1/4″ & XLR) ​
OUTPUT CONNECTORS:
XLR TO LX210AS​XLR TO LX210S NL4 TO LX12275
Processor Section
CROSSOVER FREQUENCIES:
200Hz, -24dB / OCT
PROTECTION:
PEAK / LIMITER LED INDICATOR
CONTROLS:
BASS GAIN, 3 DSP PRESETS
OPERATIONAL VOLTAGE:
100-240V, 50/60Hz SWITCHABLE
Construction
COLOR:
BLACK
HANDLES:
TWO SIDE WOOD RECESSED
MATERIAL:
MDF PLYWOOD
RIGGING:
POLE MOUNTÂ SOCKET, 2 X TOUCH-CONNECT
FEET:
8 RUBBER FEET
GRILLE:
STEEL
Dimensions
WIDTH:Â 25.6 INCH / 650 mm
DEPTH:Â 19 INCH / 480 mm
HEIGHT:Â 14.2 INCH / 360 mm
WEIGHT:Â 62.8 LB / 28.5 KG
Additional specifications available at Sound Barrier’s website
